HMK 310 LC

Maximum Power

264 HP (197 kW) @1900 rpm

Bucket Digging Force (ISO)

21.300 kgf

Bucket capacity

1,6 m³

  • View Specs & Dimensions Brochure
HİDROMEK H4 Series HMK 310 LC is a high-performance heavy-duty excavator designed to deliver maximum productivity, efficiency, and speed. It is built with advanced hydraulic technology and strong engine power to ensure superior performance in large-scale construction and excavation projects.

This model focuses on higher productivity, faster operation, and improved efficiency compared to previous series. It delivers more work in less time with increased hydraulic performance and larger bucket capacity. The machine also ensures a safe and comfortable working environment with advanced operator protection systems and excellent visibility.

Features

Higher Productivity

  • 17% more productive performance
  • 7% improved efficiency
  • 10% faster hydraulic movements
  • Larger bucket capacity for faster cycle time

Durable Build

  • Heavy-duty reinforced structure
  • High durability from strict quality-control production
  • Designed for extreme working conditions

Safe Working Environment

  • ROPS & FOPS certified cabin
  • Reduced blind spots with cameras
  • Enhanced LED lighting for night visibility
  • Safety handles and warning labels

Warning Systems

  • Automatic starting horn
  • Swing warning system
  • Travel warning system

Specifications

Engine

  • Power: 264 HP (197 kW) @ 1900 rpm
  • Torque: 1050 Nm @ 1500 rpm
  • Model: ISUZU 6HK1X
  • 6-cylinder turbocharged diesel engine
  • Displacement: 7790 cc
  • Emission Class: EU Stage V

Hydraulic System

  • Pump Type: Double variable displacement axial piston pumps
  • Max Flow: 2 × 266 L/min
  • Pilot Pump: 30.5 L/min
  • Pressure (Attachment): 350 kgf/cm²
  • Power Boost: 380 kgf/cm²
  • Travel: 350 kgf/cm²
  • Swing: 285 kgf/cm²
  • Pilot: 40 kgf/cm²

Swing System

  • Swing Speed: 10.4 rpm

Travel

  • Maximum Drawbar Pull: 25,460 kgf
  • High Speed: 5.1 km/h
  • Low Speed: 3.0 km/h

Digging Performance

  • Bucket Digging Force (ISO): 21,300 kgf
  • Bucket Capacity: 1.6 m³
  • Arm Breakout Force (ISO): 17,800 kgf

Working Dimensions

  • Boom: 6,280 mm
  • Arm: 2,500 mm
  • Maximum Digging Depth: 6,760 mm
  • Maximum Reach at Ground Level: 10,150 mm

Operating Weight

  • 32,200 kg
  • View Specs & Dimensions Brochure
